美國Cleveland Control開關
供應CLEVELAND振動器 型號: VM-25
AFS-293
主要參數:
| Item | Vibrator | |
| Type | Piston | |
| Power Source | Pneumatic/Air | |
| Voltage | Non-Electric | |
| Phase | Non-Electric | |
| Force (Lb.) | 15 | |
| Force | Linear | |
| Duty | Intermittent | |
| Max. Material in Bin (Lb.) | 100 to 175 | |
| Speed @ 80 psi (VPM) | 16,000 | |
| Speed (VPM) | 16,000 | |
| CFM @ 80 PSI | 2 | |
| PSI | 80 | |
| Inlet Port (In.) | 1/4 | |
| Outlet Port (In.) | #10-32 Tapped Exh | |
| Mounting | Any Position | |
| Housing | 304 Stainless Steel | |
| Lubrication | Suggested | |
| Overall Height (In.) | 1-1/4 | |
| Overall Length (In.) | 2-3/16 | |
| Overall Width (In.) | 5/8 | |
| Application | Manufacturing, Chemical Plants, Pharmacuetical, Packaging | |
| Includes | Grade 5 Mounting Hardware and Manual |
